Specifications

• Physical Size (HxWxD): 60x27x11 mm / 2.36x1.06x0.43 in
• Weight: 10 g / 0.35 oz
• Shell material: Plastic
• Shell color: White
• Environmental Ambient working temperature: -20 °C to 40 °C / -5 °F to 105 °F
• Environmental Humidity: 30 % to 70 % RH
• Gateway Power supply: 5 V⎓ (from USB-A port)
• Gateway Power consumption: < 1 W
• Gateway Wi-Fi Protocol: 802.11 b/g/n
• Gateway RF band: 2412 - 2472 МHz
• Gateway Max. RF power: < 20 dBm
• Gateway Range: Up to 30 m / 98 ft indoors and 50 m / 164 ft outdoors (depends on local conditions)
• TRV Bluetooth Protocol: 4.2 with BLE
• TRV RF band: 2402 - 2480 MHz
• TRV Max. RF power: < 4 dBm
• TRV Range: Up to 10 m / 33 ft indoors and 30 m / 98 ft outdoors (depends on local conditions)
• Microcontroller unit CPU: ESP-Shelly-C38F
• Flash: 8 MB
• Schedules: 20
• Webhooks (URL actions): 20 with 5 URLs per hook
• Scripting: Yes
• MQTT: Yes
• Encryption: Yes
