Caratteristiche principali: |
- Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af/at, IEEE 802.1q standards
- 4 × 10/100/1000 Base-T Ethernet ports (PoE & Data), 2 × 10/100/1000 Base-T uplink ports (Data)
- 2 K MAC address table and MAC address auto learning
- IEEE 802.3x full-duplex flow control and half-duplex backpressure flow control
- 12 Gbps switching fabric for non-blocking line-speed forwarding
- Maximum PoE output of a single port: 30 W, Total PoE output of the switch: 58 W
- ProFi Cloud web UI and App management
- 250 m network extension, PoE management, QVLAN, VLAN transparent transmission, traffic statistics, loop guard, DHCP Snooping and MAC address binding
|
Specifiche tecniche: |
| Interfaccia | 4 × 10/100/1000 Base-T Ethernet ports (PoE & Data)
2 × 100/1000 Base-T Ethernet port (Data) |
| Indicatori LED | One Link/Act LED indicator for each port
One PWR LED indicator for each device
One SYS LED indicator for each device |
| Standard network | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z, IEEE 802.1q, IEEE802.3af, IEEE802.3at |
| Velocità Switching | 12 Gbps |
| Velocità inoltro pacchetti | 8.9 Mpps |
| Protezione fulmini | Port: 6 kV
Power supply: 6 kV |
| Dimensioni (WxDxH) | 100 mm × 100 mm × 26 mm |
| PoE power supply | IEEE 802.3af/at standards PoE power supply on ports 1-4
Voltage of cores 1, 2, 4, 5 is +, and cores 3, 6, 7, 8 is - |
